- The 750W figure is ASUS's recommended PSU for the PRIME GeForce RTX 4070 SUPER 12GB GDDR6X OC Edition, not for every RTX 4070 SUPER card.
- The 550W figure is ASUS's recommended PSU for the Dual Radeon RX9060XT 8G GDDR6, not for every RX 9060 XT card.
- The RTX 4070 SUPER's 12GB is GDDR6X. The RX 9060 XT's 8GB is GDDR6.
- The RTX 4070 SUPER takes one 16-pin connector. The RX 9060 XT takes one 8-pin connector.
Side by side
| Spec | RTX 4070 SUPER | RX 9060 XT |
|---|---|---|
| Power connectors Different types | 1× 16-pin | 1× PCIe 8-pin |
| Recommended PSU | 750 W | 550 W Better |
| Slot width | 2.5 slots | 2.5 slots |
| VRAM | 12 GB Better | 8 GB |
What each number means
Power connectors
Each card needs only one power cable, but the plugs are different. The RTX 4070 SUPER uses a 16-pin plug and the RX 9060 XT uses an 8-pin, so check which one your power supply provides before you order.
Recommended PSU
ASUS's word here is "recommended," and the figure applies to these two specific ASUS cards. If you're keeping your current power supply, compare its rating with that number first.
Slot width
Slot count is a tie. Both cards are listed at 2.5 slots, so if one fits your board's slot spacing on this measure, the other does too.
VRAM
Memory is the one row in this comparison where the RTX 4070 SUPER wins, with 12GB against 8GB. If you care most about VRAM, this row settles it.
The trade-off
ASUS recommends a 550W PSU for the RX 9060 XT and 750W for the RTX 4070 SUPER. But the RTX 4070 SUPER has 12GB of VRAM, while the RX 9060 XT has 8GB.
Exact source claims
- One 16-pin power connector
Original quote
Power Connectors 1 x 16-pin
- Recommended PSU: 750W
Original quote
Recommended PSU 750W
- 2.5-slot card
Original quote
Slot 2.5 Slot
- 12GB of GDDR6X
Original quote
Video Memory 12GB GDDR6X
- One 8-pin power connector
Original quote
Power Connectors 1 x 8-pin
- Recommended PSU: 550W
Original quote
Recommended PSU 550W
- 2.5-slot card
Original quote
Slot 2.5 Slot
- 8GB of GDDR6
Original quote
Video Memory 8GB GDDR6
